21Kamstrup A/S • 55121739_A3_GB_04.2016
MULTICAL® 403
10 Set-up via front keys
A number of parameters in MULTICAL® 403 can be configured at the installation site. The
configuration is carried out via SETUP loop, which is available as long as MULTICAL® 403 remains
in transport state*, or until the configuration is ended by activating ”EndSetup”. If the meter is
commissioned, and hereby not in transport state it is necessary to break the installation seal
i.e. separating the calculator top and bottom in order to bring the meter back into SETUP loop.
Subsequently the meter must again be sealed with locking wire and/or sealing labels in order to be
used for billing purposes.
You go from USER loop to SETUP loop by pressing the left key (primary key) for 9 s. After 4 min.
without activation of the front keys the meter returns to energy reading in USER loop.
SETUP loop does not include secondary readings, and, therefore, the index number always
consists of 4 digits. In SETUP loop the right key (secondary key) is used for accessing individual
readings with the purpose of changing parameters.*****
SETUP loop Index number in
display
1.0 Customer number (N
o
1) 3-001
2.0 Customer number (N
o
2) 3-002
3.0 Date 3-003
4.0 Time** 3-004
5.0 Yearly target date 1 (mm.DD) 3-005
6.0 Monthly target date 1 (DD) 3-006
7.0 Flow sensor position: inlet or outlet flow (A-code) 3-007
8.0 Measuring unit and resolution
(B and CCC-codes are configured as e.g. ”0.001 MWh” and ”0.01 m
3
”)
3-008
9.0 M-Bus primary address (N
o
35) 3-009
10.0 Average time for min./ max. P and Q 3-010
11.0 q
hc
*** 3-011
12.0 t offset 3-012
13.0 Radio ”ON” or ”OFF” 3-013
14.0 Input A (pre-set register) 3-014
15.0 Input B (pre-set register) 3-015
16.0 Meter no. of Input A 3-016
17.0 Meter no. of Input B 3-017
18.0 TL2 3-018
19.0 TL3 3-019
20.0 TL4 3-020
21.0 t5 3-021
22.0 EndSetup 3-022
* MULTICAL® 403 remains in transport state until flow is registered for the first time.
** The clock can be adjusted under installation seal via the front keys or the PC-program
METERTOOL HCW. Furthermore, all modules can adjust the clock.
*** q
hc
can only be changed in meters configured as meter type 6. Upon attempts to access this
menu in meters configured with other country codes the display shows the message ”Off”.
