Kamstrup MULTICAL 403 Installation & Maintenance Instructions

10
411d
Reading
Tel: +44 (0)118 9311188 | Email: info@able.co.uk
Aberdeen
Tel: +44 (0)1224 725999 | Email: ab@able.co.uk
Registered Address
ABLE Instruments & Controls Ltd
Cutbush Park, Danehill, Lower Earley,
Reading, Berkshire, RG6 4UT. UK.
Web
able.co.uk
E-commerce
247able.com
10 Kamstrup A/S • 55121739_A3_GB_04.2016
MULTICAL® 403
3.3 Mounting of MULTICAL® 403 flow sensor
90° 90°
90° 90°
The flow sensor can be mounted horizontally, vertically, or at an angle.
90° 90°
The flow sensor should be mounted at 0° and can be turned downwards to 90°.

Kamstrup MULTICAL 403 Specifications

General

Type	Ultrasonic Heat Meter
Flow Sensor	Ultrasonic
Pressure Rating	PN16
Battery Life	Up to 16 years
Approval	MID Class 2
Display	LCD
Communication	M-Bus, Wireless M-Bus, Modbus, BACnet
Power Supply	Battery
Accuracy	Class 2
Protection Class	IP54
Housing Material	Composite
Flow Rate Range	0.6 m3/h to 15 m3/h
