14 Kamstrup A/S • 55121739_A3_GB_04.2016
MULTICAL® 403
5 Information codes ”INFO”
MULTICAL® 403 constantly monitors a number of important functions. If a serious error occurs in
the measuring system or the installation, a flashing “INFO” will appear in the display. The ”INFO”-
field keeps flashing as long as the error is present no matter which reading you choose. The
”INFO”-field is automatically switched off when the error has been corrected. The info code can be
displayed in in TECH loop reading 2-017-00, for indication of current errors in MULTICAL® 403. The
info code consists of 8 digits and each functionality has its own digit dedicated to the indication
of relevant information. For instance all information concerning temperature sensor t1 is shown in
the display as the second digit from the left.
Display digit
Description
1 2 3 4 5 6 7 8
Info t1 t2 0 V1 0 In-A In-B
1 No voltage supply
2 Low battery level
9 External alarm (e.g. via KMP)
1 t1 Above measuring range or switched off
1 t2 Above measuring range or switched off
2 t1 Below measuring range or short-circuited
2 t2 Below measuring range or short-circuited
9 9 Invalid temperature difference (t1-t2)
3 V1 Air
4 V1 wrong flow direction
6 V1 > q
s
for more than an hour
8 Pulse input A, leakage in system
9 Pulse input A, external alarm
8 Pulse input B, leakage in system
9 Pulse input B, external alarm
Example:
1 0 2 0 0 0 9 0
