Please set the parameters of COM number, bound rate, data bit, stop bit and the parity
bit correctly, then the RS232 commands can be sent in the Command Sending Area.
Baud rate: 2400, 4800, 9600, 19200, 38400, 57600 or 115200.
Data bit: 8.
Stop bit: 1.
Parity bit: none.
6.3 RS232 Command
Beside the button control on the front panel, the transmitter can be controlled by
sending the below commands.
Baud rate: 9600.
Data bit: 8.
Stop bit: 1.
Parity bit: none.
6.3.1 Signal Switching
Command
Function
Feedback Example
50701%
Switch to HDMI IN 1 input.
SWITCH TO HDMI1
50702%
Switch to HDMI IN 2 input.
SWITCH TO HDMI2
50710%
Enable auto-switching mode.
AUTO SWITCHING
50711%
Disable auto-switching mode.
MANUAL SWITCHING
50712%
Get the signal switching mode.
AUTO SWITCHING
MANUAL SWITCHING
6.3.2 CEC Commands
Note: The display must support CEC in order for these to work.
Command
Function
Feedback Example
50730%
Volume up the display
CEC VOLUME INCREASE
50731%
Volume down the display
CEC VOLUME DECREASE
50732%
Mute the display
CEC VOLUME MUTE
50733%
Display ON
CEC DISPLAY ON
50734%
Display OFF
CEC DISPLAY OFF
.
