KanexPro WP-HDBTKVM3 - 2 Specification; Transmitter

4K/60 2x1 Wall Plate Switcher & Extender Set
4
2. Specification
2.1 Transmitter
Input
Input
(2) HDMI
Input Connector
(2) Type-A female HDMI
Output
Output
(1) HDBT, (1) TO PC, (1) DC OUT
Output Connector
(1) RJ45, (1) Type-B USB, (1) 2-pin terminal block
Control
Control Port
(1) FIRMWARE, (1) RS232
Control Connector
(1) Micro-USB, (1) 3-pin terminal block
General
Bandwidth
10.2Gbps
HDMI Version
1.4
HDCP Version
2.2
Video Resolution
Up to 4K×2K@60Hz 4:2:0
Transmission Mode
HDBaseT
Transmission Distance
1080P/4K@60Hz ≤ 328ft/100m
Power Supply
Powered from the receiver by CATx cable.
Operation Temperature
-10℃ ~ +55℃
Storage Temperature
-25℃ ~ +70℃
Relative Humility
10%-90%
Dimensions (W*H*D)
3.5” x 4.0” x 1.7”
Net Weight
0.55 lbs. (250g)
