KanexPro WP-HDBTKVM3 - Receiver

4K/60 2x1 Wall Plate Switcher & Extender Set
5
2.2 Receiver
Input
Input
(1) HDBT, (3) USB
Input Connector
(1) RJ45, (3) Type-A USB
Output
Output
(1) HDMI
Output Connector
(1) Type-A female HDMI
Control
Control port
(1) FIRMWARE, (1) RS232
Control Connector
(1) Micro-USB, (1) 3-pin terminal block
General
Bandwidth
10.2Gbps
HDMI Version
1.4
HDCP Version
2.2
Video Resolution
Up to 4K×2K@60Hz 4:2:0
Transmission Mode
HDBaseT
Transmission Distance
1080P/4K@60Hz ≤ 328ft/100m
AC Adapter Input Power
100V~240V AC, 50/60Hz
Input Power
24V DC 1.25A
Power Consumption
23W (Max, work with the transmitter)
Operation Temperature
-10℃ ~ +55℃
Storage Temperature
-25℃ ~ +70℃
Relative Humility
10%-90%
Dimension (W*H*D)
136mm x 25.5mm x 95mm
Net Weight
365g
