Instructions for use ELECTROmatic M/C and PM/PC
3 Description of the product | 3.6 Technical specifications of the ELECTROmatic
26 / 78
Media
Water quality according to DIN EN
7494-2
Tap water
Water hardness 8.4 to 12 °dH
pH 7.2 to 7.8
System pressure 1.8 to 5 bar / 26 to 72.5 psi
Spray air 1.0 to 2.5 bar / 14.5 to 36.2 psi
Spray water 0.8 to 2.0 bar / 11.6 to 29 psi
Cooling air exit at the motor coupling 6 to 9 Nl/min
Customer-site air filtration 50 microns
Customer water filtering 80 microns
Ideal settings at the dental unit
System pressure 3 bar / 43.5 psi
Spray air pressure
1)
1 bar / 14.5 psi
Spray water pressure
1)
0.8 bar / 11.6 psi
1)
pressure measured at the motor coupling using a pressure gauge Mat. no.
1.003.1050.
Speed
Speed range of the Motor KL 703 100 - 40,000 min
-1
(rpm)
Speed range of the
COMFORTdrive 200 XDR
20,000 - 200,000 min
-1
(rpm)
Motor torque
Torque of the Motor KL 703 max-
imum
3 Ncm
Torque of the Motor KL 703 min-
imum
0.15 Ncm
Maximum torque
COMFORTdrive 200 XDR
0.4 Ncm
Electrical ratings
Input voltage 36 V DC
Power 120 W
