Instructions for use ELECTROmatic M/C and PM/PC
5 Startup | 5.1 Connector
48 / 78
Note
The ELECTROmatic has an automatic spray air and spray water shut-off. The
automatic spray air and spray water shut-off prevents the following:
- Dripping of spray water after the motor is stopped
- Continuous exit of water/air through leaky treatment centres
▶ Connect the 4-hole, 5-hole or 6-hole turbine hose of the dental unit to the
filter of the ELECTROmatic.
or
▶ If the turbine hose of the dental unit has a 2-hole or 3-hole connector, re-
place the turbine hose with a 4-hole, 5-hole or 6-hole turbine hose or use a
commercial adapter.
See also:
2 11 Accessories and consumables, Page 71
5.1.3 Connect the motor
▶ Slightly wet the O-rings on the connection hose with KAVOspray.
▶ Connect the motor to the supply hose and twist.
ð The correct attachment position is attained automatically.
▶ Screw tight the hose-side union nut proceeding in the direction of the ar-
row.
