4 Installation | 4.6 Installation position 3: Mount on a holder or on the backside of a holder
38 / 78
Assembly variant b)
The following parts from the scope of delivery and the installation set are
needed:
▪ 2x screws
▶ Use screws to screw the control unit directly to the holder.
Assembly variant c)
The following parts are needed:
▪ Double-sided adhesive tape
▶ Stick pads in the 4 recesses on the underside of the device and then set up
the control unit.
ð The pads keep the control unit from slipping.
