Kawai MP6 - Page 91

91
13. MIDI Implementation
NRPN MSB/LSB
Status 2nd Byte 3rd Byte
BnH 63H mmH
BnH 62H llH
n = MIDI channel number : 0H - fH (ch.1 ~ ch.16)
mm = MSB of the NRPN parameter number
ll = LSB of the NRPN parameter number
NRPN numbers implemented in MP6 are as follows
NRPN # Data
MSB LSB MSB Function & Range
01H 08H mmH Vibrato Rate mm:00H - 7FH (-64 ~ 0 ~ +63) Default = 40H
01H 09H mmH Vibrato Depth mm:00H - 7FH (-64 ~ 0 ~ +63) Default = 40H
01H 0aH mmH Vibrato Delay mm:00H - 7FH (-64 ~ 0 ~ +63) Default = 40H
01H 20H mmH Cuto mm:00H - 7FH (-64 ~ 0 ~ +63) Default = 40H
01H 21H mmH Resonance mm:00H - 7FH (-64 ~ 0 ~ +63) Default = 40H
01H 63H mmH Attack time mm:00H - 7FH (-64 ~ 0 ~ +63) Default = 40H
01H 64H mmH Decay time mm:00H - 7FH (-64 ~ 0 ~ +63) Default = 40H
01H 66H mmH Release time mm:00H - 7FH (-64 ~ 0 ~ +63) Default = 40H
* Ignoring the LSB of data Entry
* It is not aected in case of modifying cuto if tone does not use the DCF.
RPN MSB/LSB
Status 2nd Byte 3rd Byte
BnH 65H mmH
BnH 64H llH
n = MIDI channel number :0H-fH(ch.1 ~ ch.16)
mm = MSB of the RPN parameter number
ll=LSB of the RPN parameter number
RPN number implemented in MP6 are the followings
RPN # Data
MSB LSB MSB LSB unction & Range
00H 00H mmH llH Pitch bend sensitivity
mm:00H-0cH (0~12 [half tone]),ll:00H Default=02H
00H 01H mmH llH Master ne tuning
mm,ll :20 00H - 40 00H - 60 00H (-8192x50/8192 ~ 0 ~ +8192x50/8192 [cent])
00H 02H mmH llH Master coarse tuning
mm:28H - 40H - 58H(-24 ~ 0 ~ +24 [half tone]), ll:Ignored(as 00H)
7fH 7fH -- -- RPN NULL
Program Change
Status nd Byte
CnH ppH
n=MIDI channel number :0H-fH(ch.1 ~ ch.16)
pp=Program number :00H - 7fH(0 ~- 127) Default = 00H
Pitch Bend Change
Status 2nd Byte 3rd Byte
EnH llH mmH
n=MIDI channel number :0H-fH(ch.1 ~ ch.16)
mm,ll=Pitch bend value :00 00-7f 7fH(-8192~0~+8192) Default = 40 00H
