3 Transport/Temporary Storage/Disposal
3.1 Checking the condition upon delivery
1. On transfer of goods, check each packaging unit for damage.
2.
In the event of in-transit damage, assess the exact damage, document it and
notify KSB or the supplying dealer (as applicable) and the insurer about the
damage in writing immediately.
3.2 Transport
DANGER
Lifting unit falling off the pallet
Risk of injury by falling lifting unit!
▷ Always transport the lifting unit in horizontal position.
▷ Give due attention to the weight data and the centre of gravity.
▷ Never suspend the lifting unit by its power cable.
▷ Use suitable, approved transport equipment, e.g. crane, forklift or pallet trucks.
Table 4: Weight
Sizes
Weight
1)
[kg]
U1.60D
U1.60E
41
42
U2.100D
U2.100E
48
49
US2.100D
US2.100E
56
67
UZ1.150D
UZ1.150E
100
111
UZS1.150D
UZS1.150E
116
127
✓ The lifting unit has been checked for in-transit damage.
1.
Use suitable transport equipment (in acc. with weights table).
2. Transport the lifting unit to the place of installation.
3. Remove the transport fixtures.
For safe transport, the lifting unit is bolted to the disposable pallet by means of
brackets 732.
4. Use the recessed grips provided at the bottom of the lifting unit to lift the unit
and place it down at the place of installation.
3.3 Storage/preservation
If commissioning is to take place some time after delivery, we recommend that the
following measures be taken for storing the lifting unit:
CAUTION
Damage during storage by frost, humidity, dirt, UV radiation or vermin
Corrosion/contamination of the lifting unit!
▷ Store the lifting unit in a frost-proof, roofed area.
1)
Unit weight without water fill
3 Transport/Temporary Storage/Disposal
10 of 86
