10.2 Connection examples
10.2.1 mini-Compacta U60, U100, US100
NOTE
Rooms containing lifting units shall be of sufficient size to give a working space of
at least 60 cm around and above all parts to be operated or serviced.
1
1
a) b)
Fig. 42: Connection example a) mini-Compacta U60, b) U100 and US100
(1) Flood level
