Number Connection for
Vent DN 70
Discharge line 2 x DN 50 (DN 32)
10.5 Types of connection
mini-Compacta U1.60, U2.100, US2.100
Connection to floor-mounted toilet bowl
mini-Compacta U1.60
Connection to wall-mounted toilet bowl
mini-Compacta U2.100, US2.100
Connection to wall-mounted toilet bowl
mini-Compacta U1.60, U2.100, US2.100
Pit installation
10 Related Documents
74 of 86
