10.2.2 mini-Compacta UZ150, UZS150
NOTE
Rooms containing lifting units shall be of sufficient size to give a working space of
at least 60 cm around and above all parts to be operated or serviced.
1
Fig. 43: Connection example mini-Compacta UZ150, UZS150
(1) Flood level
