KEB COMBIVERT F5 Series Installation Guideline

GB - 47
CP-Parameter
Dis- Parameter Setting range Reso- De- Unit En- Origin
play lution fault ter
CP.0 password input 0...9999 1 - - - ud.1
CP.1 actual frequency display -400...400 0,0125 0 Hz - ru.3
CP.2 set frequency display -400...400 0,0125 0 Hz - ru.1
CP.3 inverter status display 0...255 1 0 - - ru.0
CP.4 apparent current 0...6553,5 0,1 0 A - ru.15
CP.5 apparent current/peak value 0...6553,5 0,1 0 A - ru.16
CP.6 utilization 0...65535 1 0 % - ru.13
CP.7 intermediate circuit voltage 0...1000 1 0 V - ru.18
CP.8 interm. circuit vol./peak value 0...1000 1 0 V - ru.19
CP.9 output voltage 0...778 1 0 V - ru.20
CP.10 minimal frequency 0...400 0,0125 0 Hz - op.6
CP.11 maximal frequency 0...400 0,0125 0 Hz - op.10
CP.12 acceleration time 0,00...300,00 0,01 5 s - op.28
CP.13 deceleration time (-1=CP.12) -0,01...300,00 0,01 5 s - op.30
CP.14 s-curve time 0,00...5,00 0,01 0 s - op.32
CP.15 boost 0,0...25,5 0,1 2 % - uf.1
CP.16 rated frequency 0...400 0,0125 50 Hz - uf.0
CP.17 voltage stabilization 1...650 (off) 1 0 V E uf.9
CP.18 switching frequency 0...LTK 1 LTK - E uf.11
CP.19 fixed frequency 1 -400...400 0,0125 5 Hz - op.21
CP.20 fixed frequency 2 -400...400 0,0125 50 Hz - op.22
CP.21 fixed frequency 3 -400...400 0,0125 70 Hz - op.23
CP.22 DC braking / mode 0...9 1 7 - E pn.28
CP.23 DC braking / time 0,00...100,00 0,01 10 s - pn.30
CP.24 max. ramp current 0...200 1 140 % - pn.24
CP.25 max. constant current 0...200 1 200:off % - pn.20
CP.26 speed search condition 0...15 1 8 - E pn.26
CP.27 quick stop time 0,00...300,00 0,01 2 s - pn.60
CP.28 reaction of ext. overtemperat. 0...7 1 7 - - pn.12
CP.29 analog output 1 / function 0...20 1 2 - E an.31
CP.30 analog output 1 / amplification -20,00...20,00 0,01 1 - - an.33
CP.31 relay output 1 / function 0...70 1 4 - E do.2
CP.32 relay output 2 / function 0...70 1 27 - E do.3
CP.33 relay output 2 / switching level ±30000,00 0,01 4 - - le.3
CP.34 source of rotation direction 0...9 1 2 - E op.1
CP.35 AN1 set value selection 0...2 1 0 - E an.0
CP.36 AN1 zero hysteresis -10,0...10,0 0,1 0,2 % - an.4
