KEB COMBIVERT F5 Series Installation Guideline

32
2.3 Technical Data
2.3.1 230 V-class
Product Description
Inverter Size
Housing size
Phases
Output rated power
Max. rated motor power
Output rated current
Max. short time current
OC-tripping current
Input rated current
Max. permissible mains fuse (inert)
Rated switching frequency
Max. switching frequency
Power loss at rated operation
Min. braking resistor
Typ. braking resistor
Max. braking current
Mains voltage U
N
Mains frequency
Input rated voltage
Output voltage
Output frequency
Min. motor line cross section
Max. motor line length (shielded)
13 14
EE
33
[kVA] 9,5 13
[kW] 5,5 7,5
[A] 24 33
[A] 36 49,5
[A] 43 59
[A] 31 43
[A] 35 50
[kHz] 8 4
[kHz] 16 16
[W] 290 350
[Ohm] 16 16
[Ohm] 27 20
[A] 25 25
[V] 180...260 ±0
[Hz] 50 / 60 ±2
[V] 230
[V] 3 x 0...U
N
[Hz] 0...400
[mm²] 6 10
[m] 100
