GB - 50
CP.29 Analog output 1 / Function
Value Function Standardization 0...100 % (±100 %)
0 absolute actual frequency CP.3 0...100 Hz
1 absolute set frequency CP.2 0...100 Hz
2 actual frequency CP.3 0...±100 Hz
3 set frequency CP.2 0...±100 Hz
4 output voltage CP.9 0...500 V
5 DC voltage CP.7 0...1000 V
6 apparent current CP.4 0...2 • Irated
7 active current ru.17 0...2 • ±Irated
8-10 application mode only
11 absolute active current ru.17 0...2 • Irated
12 power mod. temperature ru.38 0...100°C
13 motor temperature ru.46 0...100 °C
14-18 application mode only
19 ramp output frequency ru.2 0...±100 Hz
20 absolute ramp output frequency ru.2 0...100 Hz
CP.32 defines the function of analog output 1.
CP.28 Reaction of external overtemperature
This parameter determines the response of the drive on the external temperature
monitoring (factory setting = off). In order to activate this function the power circuit
terminals T1/T2 must be connected in accordance with the instruction manual Part 2.
After that the response can be adusted according to following table. If overheat no longer
exists, the message E.ndOH (or A.ndOH) is output. Only then the error can be reset or
the automatic restart can be carried out.
CP.28 Display Reaction Restart
0 E.dOH Immediate disabling of modulation Remove fault;
1* A.dOH Quick stopp. / disabling of modul. after reaching speed 0 Actuate
2* A.dOH Quick stopping/holding toruqe at speed 0 reset
3 A.dOH Immediate disabling of modulation autom. reset,
4* A.dOH Quick stopp. / disabling of modul. after reaching speed 0 if fault is no
5* A.dOH Quick stopping/holding torque at speed 0 longer present
6* keine No effect on the drive; With CP.31/32 = 9 an external
module can be controlled (e. g. fan) - inapplicable -
7 keine No effect on the drive; !No malfunction! External
Temperature monitoring is not activated.
*) If the motor is still too hot after 10 seconds, the error E.dOH is triggered and the
modulation is switched off!
