KEB COMBIVERT F5 Operation Manual

120
Diagnostic Solutions
Item # Check/Solution
Monitor the Command Speed
and Motor (Encoder) Speed
If the Command Speed and Motor (Encoder) Speed match, but the
elevator does not travel at the correct speed:
Check Active Speed and Active Prole from Diagnostics and check
whether the corresponding speed setting in the LS parameters is
correct. Refer to Monitor the Active Speed and Active Prole for ad-
ditional info.
Ensure the Machine Data parameters LN01-03 are correct. Incorrect
data may cause the elevator to run too fast or too slow. Refer to LN
parameter descriptions for further information.
If the US04 Control Type is analog type, verify correct US06 Contract
Speed and LS02 High Speed settings. US06 Contract Speed dic-
tates the maximum setting for the LS02 High Speed and the LS02
High Speed dictates the speed corresponding to 10V.
If the US04 Control Type is analog type, verify the correct Raw and
Processed (Analog) Patterns in Diagnostics Screen #5 as well as any
Analog Pattern Gain in LA05.
If the US04 Control Type is serial type, verify the correct Field Bus
Control Word and Raw Com Data in Serial Diagnostics Screen as
well as proper eld bus conguration (Refer to FB parameter descrip-
tions for further information.
If the Command Speed and Motor (Encoder) Speed do NOT match:
See Check whether Maximum Torque setting is reached and high
enough for normal operation.
See Check whether Inverter Maximum Current Limit is being
reached.
See (Voltage) Modulation Grade limit Reached
Monitor the Active Speed
and Active Prole (Diagnostic
Screen #11)
The Active Speed will indicate which speed setting is selected according
to the US04 Control Type and LI03 Special Functions.
The Active Prole will indicate if any modes of operation (eg. UPS Op-
eration, Earthquake, Emergency) corresponding to programmed input
functions (LI04-11) are active. In the case of certain modes of opera-
tion, the maximum speed may be limited to a speed lower than that
selected and show as the Active Speed (above).
