KEB COMBIVERT F5 Operation Manual

87
Diagnostics and Troubleshooting
Diagnostic Screen # 9
Operator Software Date (ddmm.y) Operator Software Version
Drive Software Version Drive Cong ID
Drive Software Date (ddmm.y) Enc. Interface Software Date
Diagnostic Screen # 10
Inverter Status Active Prole
Elevator Speed Active Speed
Elevator Position Leveling Distance
Diagnostic Screen # 11
NTSD Speed 1 Up NTSD Speed 1 Down
NTSD Speed 2 Up NTSD Speed 2 Down
NTSD Speed 3 Up NTSD Speed 3 Down
Diagnostic Screen # 12
Total Runs Motor Frequency
Calculated Motor Pole Motor Power
Motor Speed Motor Current
Diagnostic Screen # 13
Car Load Post Pretorque
Brake Release Time Elevator Position
Field Bus Pretorque Actual Torque
Serial Diagnostics (*For Development Purposes)
Field Bus Control Word
0000 0000 0000 0000
Raw Com Data
0000 0000 0000 0000
0000 0000 0000 0000
CAN Diagnostics
Control Word and Status Word information
Diagnostic Screen Log
MM/DD/YYYY HH:MM:SS
(Most Recent) Fault or Special Operating Mode
.
.
.
.
MM/DD/YYYY HH:MM:SS
(Oldest) Fault or Special Operating Mode
