When C5 setting is 10, maximum current value is controller maximum operating
current value (ie, limit current value); when setting is 9, maximum current value divided by
1.10, when setting is 8, maximum current value divided by 1.15 and so on.
After finishing C5 parameter setting, hold button (SW) shortly to save the
current set values and enter C6 parameter setting interface.
○ C6 Backlight Brightness Adjustment Mode
Enter C6 parameter setting interface after C5 parameter setting is finished, C6
parameter column flashes.
C6 parameter setting interface
C6 is the meter backlight brightness adjustment mode. The default value is 3, and
setting range is 1-5, hold button (UP) or button (DOWN) shortly for
selection.
C6 parameter definition table：
