DISASSEMBLY INSTRUCTIONS OUTDOOR UNIT SIZES 30−36 (CONT)
Steps
7.Remove the electric box
electric box
electric box
(fireproofing)
8.Remove the motor
motor
Twist off the tapping screws securing the motor. Pull
out the motor’s leading wire pin and then remove the
motor.
.
Procedure
Twist o the screws on the electric box, and cut o the tieline
with scissors or pliers. Pull out the wiring terminal and pull it
upwards to remove the electric box.
Twist o the screws on the electric box (reproong) with a
screwdriver. Next, remove the electric box (reproong).
