Keithley 2001 Repair Manual

Replaceable Parts
4-3
R845
R847
R848,851-853
R849,855,858,865
R850
R854
R856,857
R860
R863
U800,801
U802
U803,804
U806
U807
U808
U809
U810,811
U812
U813
VR801
Y800
RES,2K,.1%,1/10W,METAL FILM
RES, 3.2K,.1%, 1/10W, METAL FILM
RES, 49.9, 1%, 125mW, METAL FILM (1206)
RES, 100, 1%, 125mW, METAL FILM (1206)
RES,100,1%,1/8W,METAL FILM
RES,1.62K,1%,1/8W,METAL FILM
RES,10,5%,125MW,METAL FILM(1206)
RES, 150K, 5%, 125MW, METAL FILM (1206)
RES, 3.01K, 1%, 125MW, METAL FILM(1206)
IC, 8 STAGE SHIFT/STORE,MC14094BD(SOIC)
IC, OP-AMP, NE5534D (SOIC)
IC, VOLT. COMPARATOR,LM311M (SOIC)
IC, VOLT COMPARATOR LM393D(SOIC)
IC, QUAD COMPARATOR,LM339D (SOIC)
PROGRAM
IC,OP-AMP,OPA602AP
IC, OP-AMP,LT1097
IC, DUAL D-TYPE F/F, 74HC74(SOIC)
IC, OPA177GS (SOIC)
DIODE,ZENER 6.4V,IN4579 (DO-7)
OSCILLATOR CMOS, 7.68 MHZ
R-263-2K
R-263-3.2K
R-391-49.9
R-391-100
R-88-100
R-88-1.62K
R-375-10
R-375-150K
R-391-3.01K
IC-772
IC-802
IC-776
IC-775
IC-774
2001-802-**
IC-703
IC-803
IC-773
IC-960
DZ-73
CR-31
** Order present Þrmware revision level for main CPU (i.e., 2001-802-A05).
Table 4-1 (continued)
Model 2001 A/D board, parts list
Circuit
Desig. Description
Keithley
Part No.
