Keithley 2001 Repair Manual

Replaceable Parts
4-8
Q506,511
Q510
Q512
Q514
Q515,517
Q525
Q527
Q528
Q529,530
Q531,536,537
Q532,540,545
Q533
Q534,535
Q539
Q542,546
Q543
Q548,549
TRANS,N-CHAN FET, BUK 456-1000B (TO-220)
TRANS, N-CHAN JFET, SST4391 (SOT-23)
TRANS, N-CHAN. DUAL JFET, U441
TRANS, N-CHAN JFET SMP4338(SOT-23)
TRANS, N-CHANNEL FET, J210(TO-92)
TRANS,N CHANNEL JFET,SELECTED J210
TRANS, SELECTED TG-128 (T0-92)
TRANS, N-CHAN MOSFET, MTG9N50E (TO-218)
DIODE CURRENT REG CR200(T0-46)
TRANS, PNP, MMBT3906L(SOT-23)
TRANS, NPN, MMBT3904 (SOT-23)
TRANS, N-CHAN DMOS FET TN2504N8 (SOT-89)
TRANS, P-CHAN, MOSFET, TP0610T(SOT-23)
TRANS, N-CHAN JFET, SST4393(SOT-23)
TRANS, P CHANNEL JFET, J270 (TO-92)
TRANS,CURRENT REGULATOR,CR430
TRANS,N CHANNEL FET,2N4392 (TO-92)
TG-247
TG-250
TG-235
TG-257
TG-176
TG-167-1
31841A
TG-291
TG-218
TG-244
TG-238
TG-261
TG-259
TG-263
TG-166-1
TG-219
TG-128-1
R100
R102,129
R103
R104,117,120
R105
R107
R108
R109
R110
R111
R114
R116,118
R122
R123
R124-128
R200
R201
R203,222
R204,242,243,245,R267-269
R209,211,223,232,249,255
R210,277
R212,R235,238
R213
R214,225,251-253,256,280
R215
R216,217
R218,282
R219-221
R226,230
RES, 470, 5%, 10W, VERTICAL MOUNT
RES,243K, 1%, 125MW, METAL FILM(1206)
RES, 140K, 1%, 125MW, METAL FILM(1206)
RES, 499K, 1%, 125MW, METAL FILM(1206)
RES, 100K, 1%, 125mW, METAL FILM (1206)
RES, 562K, 1%, 125MW, METAL FILM (1206)
RES, 33, 5%, 250mW, METAL FILM (1210)
RES, 475, 1%, 125mW, METAL FILM (1206)
RES, 2.49K, 1%, 125MW, METAL FILM (1206)
RES, 59K, 1%,125MW,METAL FILM(1206)
RES, 1M, 5%, 1/2W, FLAME PROOF
RES, 20K, 5%, 125MW, METAL FILM (1206)
RES, 100K, 5%, 125mW, METAL FILM (1206)
RES, 20K, 5%, 250MW, METAL FILM (1210)
RES,10K,5%,125MW,METAL FILM(1206)
RES, 1.8M, 5%, 125MW, METAL FILM (1206)
RES, 1.2M, 5%, 125MW, METAL FILM(1206)
RES, 68K, 5%, 125MW METAL FILM (1206)
RES, 200K, 5%, 125MW, METAL FILM(1206)
RES, 2K, 5%, 125MW, METAL FILM(1206)
RES, 137, 1%, 125MW, METAL FILM (1206)
RES, 20K, 5%, 125MW, METAL FILM (1206)
RES, 10K, 5%, 250MW, METAL FILM(1210)
RES,10K,5%,125MW,METAL FILM(1206)
RES NET, 500, 24.5K,0/1%, 125MW THIN FILM
RES, 15, 5%, 125MW, METAL FILM(1206)
RES, 15K, 1%, 125mW, METAL FILM (1206)
RES, 120K, 5%, 125MW, METAL FILM(1206)
RES, 22K, 5%, 125MW, METAL FILM(1206)
R-401-470
R-391-243K
R-391-140K
R-391-499K
R-391-100K
R-391-562K
R-376-33
R-391-475
R-391-2.49K
R-391-59K
R-394-1M
R-375-20K
R-375-100K
R-376-20K
R-375-10K
R-375-1.8M
R-375-1.2M
R-375-68K
R-375-200K
R-375-2K
R-391-137
R-375-20K
R-376-10K
R-375-10K
TF-234
R-375-15
R-391-15K
R-375-120K
R-375-22K
Table 4-2 (continued)
Model 2001 analog board, parts list
Circuit
Desig. Description
Keithley
Part No.
