Keithley 2001 Repair Manual

Replaceable Parts
4-10
R365
R366
R367
R368
R369
R370,382
R371
R372,392
R375
R377
R379,380
R381
R384
R385,396
R394
R398
R399
R400
R401
R402,404
R403,424
R408,409
R410,411
R413,422,423,425,426,428
R414,421
R415,419,420
R416-418
R427
R429
R432-441,443
R442
R444
R446,445
R447-R449
R501,560
R503
R504,582,536
R505,512,517,570,571,577
R506,566,537
R507
R513
R514
R515,521
R516
R520
R522
R526
RES, 78.7K, .1%, .2W, WIREWOUND
RES,1M,0.1%,1/4W,METAL FILM
RES,22M,5%,1/4W,COMPOSITION OR FILM
RES, 4.99K, 1%, 125mW,METAL FILM (1206)
RES, 36, 5%, 250MW, METAL FILM(1210)
RES, 10K, 5%, 250MW, METAL FILM(1210)
RES, 3.3K 5%, 125MW METAL FILM (1206)
RES,2.2M,10%,1/2W, COMPOSITION
RES, 2.2,5%, 125MW, METAL FILM(1206)
RES, 68, 5%, 125MW, METAL FILM(1206)
RES, 1M, 5%, 125MW, METAL FILM (1206)
RES, 100, 5%, 125MW, METAL FILM (1206)
RES, 68K, 5%, 125MW METAL FILM (1206)
RES, 510, 5%, 250MW, METAL FILM(1210)
RES NET, 100K, 9.9M, METAL FILM
RES, 1K, .1%, 1W, WIREWOUND
RES, 150, 10%, 1W, METAL FILM
RES, 150, 10%, 1/2W, METAL FILM
RES, 500, 1%, 1/2W, METAL FILM
RES, 2.15K, 1%, 125MW, METAL FILM(1206)
RES, 100K, 5%, 250MW, METAL FILM(1210)
RES, 1.5K, 5%, 250MW, METAL FILM(1210)
RES, 470,5%, 125MW, METAL FILM(1206)
RES, 100K, 5%, 125mW, METAL FILM (1206)
RES,100K,1%,125mW,METAL FILM(1206)
RES, 200K, 5%, 250MW, METAL FILM (1210)
RES, 68K, 5%, 125MW METAL FILM (1206)
RES, 2K, 5%, 125MW, METAL FILM(1206)
RES, 1M, 5%, 125MW, METAL FILM (1206)
RES,1K,5%,125MW,METAL FILM(1206)
RES, 330, 5%, 125MW, METAL FILM(1206)
RES, 39K, 5%, 250mW, METAL FILM (1210)
RES,4.7K,5%,125MW,METAL FILM(1206)
RES,10K,5%,125MW,METAL FILM(1206)
RES,10K,1%,125mW,METAL FILM(1206)
RES, 150K, 5%, 125MW, METAL FILM (1206)
RES, 33K, 5%, 125MW, METAL FILM(1206)
RES, 1M, 5%, 125MW, METAL FILM (1206)
RES, 15K, 1%, 125mW, METAL FILM (1206)
RES,4.7K,5%,125MW,METAL FILM(1206)
RES, 10M, 5%, 125MW, METAL FILM(1206)
RES, 470,5%, 125MW, METAL FILM(1206)
RES, 22K, 5%, 125MW, METAL FILM(1206)
RES, 120K, 5%, 250mW, METAL FILM (1210)
RES, 330, 5%, 125MW, METAL FILM(1206)
RES, 2.15K, 1%, 125MW, METAL FILM(1206)
RES, 100, 5%, 125MW, METAL FILM (1206)
R-406-78.7K
R-433-1M
R-76-22M
R-391-4.99K
R-376-36
R-376-10K
R-375-3.3K
R-1-2.2M
R-403-2.2
R-375-68
R-375-1M
R-375-100
R-375-68K
R-376-510
TF-251
R-249-1
R-411-150
R-411-150
R-411-500
R-391-2.15K
R-376-100K
R-376-1.5K
R-375-470
R-375-100K
R-391-100K
R-376-200K
R-375-68K
R-375-2K
R-375-1M
R-375-1K
R-375-330
R-376-39K
R-375-4.7K
R-375-10K
R-391-10K
R-375-150K
R-375-33K
R-375-1M
R-391-15K
R-375-4.7K
R-375-10M
R-375-470
R-375-22K
R-376-120K
R-375-330
R-391-2.15K
R-375-100
Table 4-2 (continued)
Model 2001 analog board, parts list
Circuit
Desig. Description
Keithley
Part No.
