5½ Digit Multimeter Calibration Manual Section 2:
2110-905-01 Rev. A / July 2012 2-11
45. Set the Model 5700A output to 1MΩ.
46. Adjust full scale measurement by sending the following command:
CAL:PROT:DC:STEP 2,<ACTUAL CALIBRATOR OUTPUT>
47. Wait until the following message is displayed on the Model 2110:
Cali OK
48. Set the Model 5700A output mode to STANDBY.
49. Configure the Model 2110 for 4-wire, 10 MΩ resistance measurements by sending the following
command:
CONF:FRES 1E7
50. Set the measurement rate to 10 PLC by sending the following command:
FRES:NPLC 10
51. Set the Model 5700A to 0 Ω and the output mode to OPERATE.
52. Adjust input offset by sending the following command:
CAL:PROT:DC:STEP 1,0
53. Wait until the following message is displayed on the Model 2110:
Cali OK
54. Set the Model 5700A output to 10 MΩ.
55. Adjust full scale measurement by sending the following command:
CAL:PROT:DC:STEP 2,<ACTUAL CALIBRATOR OUTPUT>
56. Wait until the following message is displayed on the Model 2110:
Cali OK
57. Set the Model 5700A output mode to STANDBY.
Ohms, high range adjustment (100 MΩ)
1. Set the Model 5700A to 0 Ω, 2 WIRE COMP OFF, EX SNS off, EX GRD off, and the output mode
to STANDBY.
2. Using shielded, low thermal EMF cables, connect the Fluke 5700A output HI, output LO, sense
HI, and sense LO terminals to the Model 2110 input HI, input LO, sense HI, and sense LO
terminals. Allow connections to stabilize for a minimum of five minutes before proceeding.
3. Configure the Model 2110 for 2-wire, 100 MΩ resistance measurements by sending the following
command:
CONF:RES 1E8
4. Set the measurement rate to 10 PLC by sending the following command:
RES:NPLC 10
5. Set the Model 5700A output to 10 MΩ
6. Set the Model 5700A output mode to OPERATE.
7. Adjust to 10 percent of scale by sending the following command:
CAL:PROT:DC:STEP 1,<ACTUAL CALIBRATOR OUTPUT>
8. Wait until the following message is displayed on the Model 2110:
Cali OK
