2: General overview Model 2110 5½ Digit Multimeter
2-12 2110-901-01 Rev. C/August 2013
Keys, menus, and selection Description
Press the CONFIG key to display configuration options.
Use â–º and â—„ keys to select bandwidth. Refer to Bandwidth and
resolution for AC measurements (on page 3-44) for details.
Use â–º and â—„ keys to display additional selections. Refer to Range
selection (on page 3-39) for details.
Press the CONFIG key to display configuration options.
Use â–º and â—„ keys to select resolution adjustment. Refer to
Resolution and integration time (on page 3-41) for information about
the number of power line cycles (NPLC).
Use â–º and â—„ keys to display additional selections. Refer to Range
selection (on page 3-39) for details.
Press the CONFIG key to display configuration options.
Refer to Aperture and resolution for frequency and period
measurements (on page 3-45) for details.
Refer to Frequency and period measurements (on page 3-12) for
information about RANGE and INPUT JACK selections.
Press the CONFIG key to display configuration options.
Select CONT RES. Use the â—„ and â–º, â–², and â–¼ keys to set the
Ω
Ω
Press the CONFIG key to display configuration options.
PT100, D100, F100,
Use â–º and â—„ keys to select a sensor type. Refer to Temperature
measurement (on page 3-17) for details.
Select to enter coefficient values for RTD user-defined sensor types.
Refer to the documentation supplied by the manufacturer of the
RTD for information about the coefficient values.
BETA, DELTA
Select coefficient and enter values. Then use â–ºand â—„ keys to
select the digit. Then use â–²and â–¼ to increase or decrease the
Select to configure the standard platinum RTD (SPRTD) sensor.
Refer to Temperature measurement (on page 3-17) and RTD
coefficients and temperature calculation (on page 3-19) for details.
R-ZERO, A4, B4,
AX, BX, CX, DX
Use â–ºand â—„ keys to select the digit. Then use â–²and â–¼ to increase
or decrease the number.
Select to configure a negative temperature coefficient thermistor
(NTCT). Refer to Temperature measurement (on page 3-17) for
Use â–ºand â—„ keys to select the digit. Then use â–²and â–¼ to increase
or decrease the number.
Select UNITS to configure the temperature unit type.
Units for temperature measurement (Celsius, Fahrenheit, or Kelvin)
Select transducer. Where: FRTD = 4-wire as the RTD measurement
and RTD = 2-wire as the RTD measurement.
