Keithley 2601B Reference Manual

Series 2600B
System SourceMeter® Instrument Reference Manual Section 7:
TSP command reference
2600BS-901-01 Rev. B / May 2013 7-233
smuX.trigger.arm.set()
This function sets the arm event detector to the detected state.
Type TSP-Link accessible
Affected by Where saved Default value
Function
Yes
Usage
smuX.trigger.arm.set()
X
Source-measure unit (SMU) channel (for example, smua.trigger.arm.set()
applies to SMU channel A)
Details
The SMU will automatically clear all the event detectors when the smuX.trigger.initiate() function is
executed. This function should be called after the sweep is initiated.
A common example of when this function can be used is when you want the SMU to immediately perform an
action the first time through the trigger model even if a programmed trigger event does not occur.
This function can also be used to start actions on the SMU in case of a missed trigger event.
Example
smua.trigger.arm.set()
Sets the arm event detector to the
detected state for SMU channel A.
Also see
smuX.trigger.initiate() (on page 7-240)
smuX.trigger.measure.set() (on page 7-241)
smuX.trigger.source.set() (on page 7-251)
smuX.trigger.arm.stimulus
This attribute selects the event that will cause the arm event detector to enter the detected state.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
SMU reset
Instrument reset
Recall setup
Not saved
0
Usage
eventID = smuX.trigger.arm.stimulus
smuX.trigger.arm.stimulus = eventID
eventID
Event that triggers the arm detector
X
Source-measure unit (SMU) channel (for example,
smua.trigger.arm.stimulus
applies to SMU channel A)
