System SourceMeter® Instrument Reference Manual Section 2:
2600BS-901-01 Rev. B / May 2013 2-21
Press the EXIT key to return to a previous menu.
The following table contains descriptions of the configuration menus, as well as cross-references to
related information. To select a menu for single SMU instruments, press the CONFIG key and then
the front-panel key associated with the menu (see the description column in the following table). For
two-SMU instruments, press the CONFIG key, select the appropriate channel (CHANNEL-A,
CHANNEL-B) and then the front-panel key associated with the menu. To select TRIG and STORE
menus on two-SMU instruments, press the CONFIG key and then select COMMON instead of
selecting a channel.
To access, press the CONFIG
key and then:
Options For more information, see:
V-source sense, low range;
I-source low range; and
highC mode
Range (on page 2-82), Basic source-
measure procedure (on page 2-32)
V and I-measure range, V-
measure sense, low range;
Range (on page 2-82), Basic source-
measure procedure (on page 2-32)
V-source and I-source
compliance limits
Relative offset (on page 3-1)
Set off-state, control digital
I/O
Output-off states (on page 2-77)
Set trigger in, count, interval,
and delay
Triggering (on page 3-32)
Set buffer count and
destination
Source-measure concepts (on page 4-1)
Setting values
Setting a value
You can adjust a value using either the Navigation wheel method or Numeric entry method (using
the keypad).
Navigation wheel method:
1. Use the CURSOR arrow keys (or turn the navigation wheel ) to move the cursor to the digit that
needs to be changed.
2. Press the navigation wheel or the ENTER key to enter edit mode. The EDIT indicator is
illuminated.
3. Rotate the navigation wheel to set the appropriate value.
4. Press the ENTER key to select the value or press the EXIT (LOCAL) key to cancel the change.
5. To return to the main menu, press the EXIT (LOCAL) key.
