Keithley 2601B Reference Manual

Series 2600B
System SourceMeter® Instrument Reference Manual Section 7:
TSP command reference
2600BS-901-01 Rev. B / May 2013 7-285
Bit Value Description
B0
Not used
Not applicable.
B1
status.operation.instrument.smuX.trigger_overrun.ARM
Set bit indicates that the
arm event detector of the
SMU was already in the
detected state when a
trigger was received.
Bit B1 decimal value: 2
B2
status.operation.instrument.smuX.trigger_overrun.SRC
Set bit indicates that the
source event detector of
the SMU was already in
the detected state when a
trigger was received.
Bit B2 decimal value: 4
B3
status.operation.instrument.smuX.trigger_overrun.MEAS
Set bit indicates that the
measurement event
detector of the SMU was
already in the detected
state when a trigger was
received.
Bit B3 decimal value: 8
B4
status.operation.instrument.smuX.trigger_overrun.ENDP
Set bit indicates that the
end pulse event detector of
the SMU was already in
the detected state when a
trigger was received.
Bit B4 decimal value: 16
B5-B15
Not used
Not applicable.
As an example, to set bit B1 of the operation status SMU A trigger overrun enable register, set
status.operation.instrument.smua.trigger_overrun.enable =
status.operation.instrument.smua.trigger_overrun.ARM.
In addition to the above constants, operationRegister can be set to the numeric equivalent of the bit to set.
To set more than one bit of the register, set operationRegister to the sum of their decimal weights. For
example, to set bits B1 and B4, set operationRegister to 18 (which is the sum of 2 + 16).
Bit
B7
B6
B5
B4
B3
B2
B1
B0
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal
128
64
32
16
8
4
2
1
Weights
(2
7
) (2
6
) (2
5
) (2
4
) (2
3
) (2
2
) (2
1
) (2
0
)
Bit
B15
B14
B13
B12
B11
B10
B9
B8
Binary value 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1
Decimal
32,768
16,384
8,192
4,096
2,048
1,024
512
256
Weights
(2
15
) (2
14
) (2
13
) (2
12
) (2
11
) (2
10
) (2
9
) (2
8
)
Example
status.operation.instrument.smua.trigger_overrun.enable =
status.operation.instrument.smua.trigger_overrun.ARM
Uses a constant to sets
the ARM bit of the
operation status SMU A
trigger overrun enable
register.
Also see
Operation Status Registers (on page E-9)
status.operation.instrument.smuX.* (on page 7-282)
