Series 2600B

System SourceMeter® Instrument Reference Manual Appendix C:

LAN concepts and settings

2600BS-901-01 Rev. B / May 2013 C-7

8. Select Use the following IP address. The option for "Use the following DNS server addresses"

is automatically selected.

9. Set the IP address. If the IP address and subnet mask fields:

• Contain values: Record the IP address, subnet mask, default gateway, and DNS servers to use in Step

3: Configure the instrument's LAN settings (on page C-8).

• Are blank: In the IP address field, enter 192.168.1.100. In the subnet mask field, enter 255.255.255.0.

These will be used to configure the LAN settings of the instrument.

1. Click OK to close the Internet Protocol Version 4 (TCP/IPv4) Properties dialog box.

2. Click OK to close the Local Area Connection Properties dialog box.

3. Close the Network Connections window.

Windows 7: To disable DHCP:

1. Click Start > Control Panel.

2. Open Network and Sharing Center.

3. Click the Local Area Connection. The Local Area Connection Status dialog box is displayed.

4. In the items list, double-click Internet Protocol Version 4 (TCP/IPv4). The Internet Protocol

Version 4 (TCP/IPv4) Properties dialog box is displayed.

Figure 157: Internet Protocol (TCP/IP) Properties dialog box
