Model DMM7510

7½ Digit Graphical Sampling Multimeter Calibration Manual Section 4:

TSP command reference

DMM7510-905-01 Rev. A / April 2015 4-9

• ACI Adjustment (cal.adjust.ac())

 ACI Step 11, 100 µA 1 kHz, ACI 1 mA range zero

 ACI Step 12, 1 mA 1 kHz, ACI 1 mA range full-scale and 10 mA range zero

 ACI Step 13, 10 mA 1 kHz, ACI 10 mA range full-scale and 100 mA range zero

 ACI Step 14, 100 mA 1 kHz, ACI 100 mA range full-scale, 1 A and 3 A range zero

 ACI Step 15, 1 A 1 kHz, ACI 1 A range full-scale

• ACI Step 16, 2 A 1 kHz, ACI 3 A range full-scale

 AC-coupling amplitude adjustment

• ACV Step 17, 1 V 10 Hz, ACV AC coupling amplitude adjustment

 Frequency adjustment

 ACV Step 18, 1 V 1 kHz, Squarewave, Frequency adjustment

For detail on how to use cal.adjust.ac(), refer to:

• AC voltage adjustment steps 1 to 10 (on page 3-13)

• AC current adjustment steps 11 to 16 (on page 3-16)

• AC coupling adjustment step 17 (on page 3-18)

• AC frequency adjustment step 18 (on page 3-19)

This command generates an error if:

• Calibration is locked

• The step is out of sequence

• The step does not complete successfully

• The value that is passed is invalid for the step, out of range, or not needed

Also see

cal.adjust.dc() (on page 4-12)

cal.lock() (on page 4-16)

cal.unlock() (on page 4-19)
