1502872-02 - 64 -
Pos.
Description
Pos.
Description
1
Push handle
10
Rear wheel
2
Air outlet grille with
connection NW 63
11
Maintenance cover, dust
collection container
3
Operating control
12
Name plate
4
Filter housing
13
Compressed air connection
(only for product with
cleaning)
5
Connection for extraction
hose NW 45
14
Communication interface
6
Maintenance cover
15
Connection cable with plug
7
Clamp fasteners
16
Cable holder
8
Vent
17
Tool tray with cup holder
(optional)
9
Vent with pre-filter mat
Tab. 19: Positions on the product
Fig. 17: Connections
3.2 Distinguishing feature – W3/IFA certified
The product is manufactured in two versions:
• Version – non-IFA certified
• Version – IFA certified
