Kemper VacuFil Compact - Dimensions Sheet

EN
1502872-02 - 99 -
Dimensions of the basic product W
x H x D
See dimension sheet
Basic product weight kg [lbs]
65.0 [143.3]
Additional information
Fan type
Side channel blower
Extraction capacity regulation
Manual/Optional
Maximum installation environment
above sea level m [inch]
1,500 [59055]
Tab. 34: Technical data
9.4 Dimensions sheet
Fig. 30: Dimensions sheet
Symbol
Dimension
Symbol
Dimension
A
1.182 mm [46,5 inch]
E
450 mm [17,7 inch]
B
594 mm [23,4 inch]
F
Ø 63 mm [2,5 inch]/
Ø 45 mm [1,8 inch]
