3.4.3. P001 Panel card structure
1. Pulse potentiometer
2. 7-segment displays for voltage
3. X1 Flat cable connector
4. 7-segment displays for current
5. Power on LED
6. Overheat LED
7. LED for CV mode
8. LED for VRD function
9. Arc force potentiometer
10. Hot start potentiometer
11. TIG/MMA selection button
12. Remote button
2.
5.
4.
6.
1.
3.
7.
8.
9.
10.
11.
12.
