Filter cards
Information of overvoltage to
control cards A002 and A001
GND
+ 15 V
Control
To the primary rectifier
L1
L1
L2
L3
DC link +
DC link -
L3
+ 15 V
Overvoltage watch
GND
Protection circuits against wrong supply voltage
To primary rectifier
Mastertig 2000 AC/DC Z001
Mastertig 2500 AC/DC Z002
15
