Kemppi MF 33 Service Manual

Motor control card A002 (A001 = MSF)
Connectors
X1/1 Connection to A001, X9/4
X1/4 Connection to A001, X9/10
A002 / X1 / KM
X1/1 Bus +50V
X1/3 Tacho +5V
X1/4 Bus GND
X1/5 Tacho GND
A001 / X1 / MSF
X1/6 Tacho Signal
X2 Connection to panel card
A002/A001 / X2
X4/2 Start
X4/3 Motor+
X4/4 U-measurement
X4/6 Pot +5V
X4/8 Connection A001 X9/2
A002 / X4 / MF
X4/11 WF-pot
X4/12 Valve
X4/14 GND
X4/15 Motor -
X4/1 Pot GND
X4/2 Start 2
X4/3 Motor +
X4/4 Pot 2
X4/5 Start 1
X4/6 Pot +5V
X4/7 ID Bus 2
X4/8 Bus Data
X4/9 General I/O
A001 / X4 / MSF
X4/10 Valve -
X4/11 Pot 1
X4/12 Valve +
X4/13 ID Bus 1
X4/14 GND
X4/15 Motor -
24
