Structure
KM / KMS
Mains connector
and
varistors
Z001
Main circuit board
Z002
DC-link
Capasitor board
S001
Main
switch
R001
Shunt
resistor
31
P001
Panel card
A001
Control card
A002 (KM)
Wire feed
control card
Water cooler
Power
connector
