Kemppi MinarcTig 180MLP User Manual

10
Connectors
X1/1 I2 measure
X1/2 U2 measure
X1/3 D1 data
X1/4 D1 data
X1/5 D1 data
X1/6 Torch potentiometer
X1/7 Remote potentiometer
X1/8 Current control
X1/9 D2 data
X1/10 D2 data
A001 / X1
X1/11 D2 data
X1/12 Dynamics
X1/13 Powersource type
X1/14 Pedal start
X1/15 + 5 V
X1/16 GND
X2/1 GND
X2/2 Relay + 24 V
X2/3 -
X2/4 PTC
X2/5 -
X2/6 Gate control
X2/7 Overvoltage, opto
X2/8 Relay on/off
X2/9 U2 measure
X2/10 PTC
A001 / X2
X2/11 -
X2/12 Gate control
X3/1 PTC
X3/2 PTC
A001 / X3
X5/1 GND
X5/2 -
X5/3 24 V
X5/4 Pedal start
X5/5 Remote pot
X5/6 -
X5/7 + 5 V
A001 / X5
X6/1 GND
X6/2 SW 1
X6/3 SW 2
X6/4 Start
X6/5 Potentiometer
X6/6 -
X6/7 + 5 V
A001 / X6
X8/1 21 Vac
X8/2 GND
A001 / X8
X9/1 I1 measure
X9/2 I1 measure
A001 / X9
X13/1 24 V
X13/2 GND
A001 / X13
X14/1 Spark on / off
X14/2 Solenoid valve (+)
X14/3 -
X14/4 Spark on / off
X14/5 Solenod valve (-)
X14/6 -
A001 / X14
H1 Aux. voltage + 5 V (LED)
H2 Aux. voltage + 24 V (LED)
