12
Panel card P001
Connectors
X3
X2 X10
X1
X1 Connector A001
X2 Membrane panel connection
X10 Program-/service channel
P001 Connectors
Operating diagram
- Micro controller (Renesas M30262)
- Adjustment potentiometer
- Parameters selection
- Overheat protection signal light
- Main switch signal light
