21
Programming
1. Start DataMaster II and press Menu.
2. Select Renesas Programming using UART mode.
3. Use the up and down arrows to choose the program you want to download.
4. Press START on the DataMaster II keypad to start the updating process.
5. When DataMaster II display says: Connect Programmable Device, connect
DataMaster II (10-pin flat cable) to welding machine (panel card connector X10) and press CONTINUE.
6. Wait so long time that programming that Datamaster display shows: Programming Ok.
7. When updating is in progress, the DataMaster II display shows the progression of
the process as a percentage value. If the progression stops, reset the DataMaster
II by pressing ON/OFF key for 3 seconds, and start again.
