Product Manuals/Man-1088_Sigma XT_26 Page 9 of 40
CT3000 O OPTICAL DETECTOMAT 19
CT3000 T HEAT DETECTOMAT 19
ECO1002 HEAT/PHOTO System Sensor 21
ECO1003 PHOTO System Sensor 26
ECO1005 HEAT System Sensor 22
ECO1005T HEAT System Sensor 22
Although the current consumption of many detection devices would allow more than 32 to be connected to a zone, this number should
be limited to 32 to ensure that a short or open circuit on the wiring does not prevent the indication of a fire alarm from more than 32 fire
detectors and/or call points as required by European standard EN54-2.
No more than 32 devices (detectors and call points) should be fitted to any one zone.
Table 3 - Compatible detector bases and call points
Model Type Manufacturer Comments
YBN-R/6 STANDARD WITH REMOTE LED Hochiki
YBO-R/4(IS) STANDARD WITH REMOTE LED (I.S.) Hochiki
YBN-R/6SK DIODE BASE Hochiki
Must be used with LCMU
YBO-R/6R STANDARD LATCHING RELAY Hochiki
YBO-R/6RN STANDARD NON-LATCHING RELAY Hochiki
YBO-R/6RS DIODE BASE WITH LATCHING RELAY Hochiki
Must be used with LCMU
YB0-R/6PA 2 WIRE BASE Hochiki
ECO1000R STANDARD System Sensor
ECO1000BRSD DIODE BASE System Sensor
Must be used with LCMU
456821-200 STANDARD BASE Apollo
456821-201 DIODE BASE Apollo
Must be used with LCMU
ORB-MB-00001-APO Timesaver Base Apollo
ORB-DB-00003-APO Timesaver Diode Base Apollo
ORB-RB-10004-APO Timesaver Relay Base Apollo
ORB-SW-10005-APO Sav-Wire Base Apollo
Z6-BS5 STANDARD ZITON
ZC6-CP1 CALL POINT ZITON
470 OHM MCP1 CALL POINT KAC
CX 470 OHM CALL POINT Fulleon
NCP-T CALL POINT Nittan
ELECTRONICS FREE BASES ALL
Note: LCMU (Line Continuity Monitoring Device) part number K1406 allows call points mounted down line of
detectors that have been removed from diode bases to continue to operate.
Table 4 - Compatible sounders
Model Type Manufacturer Comments
BANSHEE ELECTRONIC VIMPEX
WAFER ELECTRONIC VIMPEX
FIRECRYER RANGE ELECTRONIC VOICE VIMPEX
KOBELL MOTORISED VIMPEX
ASKARI ELECTRONIC FULLEON
ROSHNI ELECTRONIC FULLEON
SQUASHNI ELECTRONIC FULLEON
SYMPHONI ELECTRONIC FULLEON
ELECTRONIC BELL ELECTRONIC FULLEON
CFB BELLS MOTORISED FULLEON
B6 AND B8 BELLS SOLENOID FULLEON
Table 5 - Compatible I.S. barriers
Model Type Manufacturer
MTL5561 DETECTION ZONE GALVANIC ISOLATOR MTL
MTL7778ac ALL SOUNDER CIRCUITS MTL
Note: Use galvanic isolator with Hochiki or Apollo detectors only
