Bluetooth® DeviceBluetooth® Device
• When a Bluetooth mobile phone is connected, the
signal strength and battery level are displayed when
the information is acquired from the device.
• If your mobile phone supports PBAP (Phone Book
Access Profile), you can display the following items
on the touch panel when the mobile phone is
connected.
– Phone book
– Dialed calls, received calls, and missed calls (up to
100 entries in total)
• Two devices for Bluetooth mobile phone and one for
Bluetooth audio can be connected at a time.
However, when [Bluetooth Audio] is selected as the
source, you can connect up to five Bluetooth audio
devices and switch between these five devices.
Bluetooth mobile phone
When a call comes in, this unit automatically enters
[TEL], and when it ends, go back to the previous
source.
When a call comes in...
Incoming Call
Name
1234XXXXXX
Device Name 1
1
Device Name 2
2
1 Phone device information
• Either hands-free phone 1 or 2 is highlighted
to indicate which phone is ringing when a call
comes in.
Touching the operation keys performs the following
actions:
[ ]
Answers a call.
[
]
Rejects a call.
• Call information is displayed if acquired.
• Phone operation is not available while the picture
from any camera is displayed.
During a call...
Talking...
Name
1234XXXXXX
NR LEVEL
–
++1
EC LEVEL
MIC LEVEL
–
++1
–
++1
DTMF
Phone Name 1
1
Phone Name 2
2
Touching the operation keys performs the following
actions:
[ ]
Ends a call.
[ ]/
[ ]
Switches between hands-free mode
and phone mode.
[DTMF] Enters DTMF (Dual Tone Multi
Frequency). You can send a text using
the keypad.
NR LEVEL
[–] / [+]
Adjusts the noise reduction level.
(–5 to 5)
EC LEVEL
[–] / [+]
Adjusts the echo volume level.
(–5 to 5)
MIC LEVEL
[–] / [+]
Adjusts the volume level of the
microphone. (–10 to 10)
• Press the VOL
J/K buttons on the monitor panel to
adjust the volume of the call or earpiece.
31
ENGLISH
