SpecificationsSpecifications
Monitor section
Picture Size (W × H) 6.75 inches (diagonal) wide
151.8 mm × 79.7 mm
Display System TN LCD panel
Drive System TFT active matrix system
Number of Pixels 1 152 000
(800H × 480V × RGB)
Effective Pixels 99.99%
Pixel Arrangement RGB striped arrangement
Back Lighting LED
USB I/F section
Connector Type Type-A
USB Standard USB 2.0 Full Speed/High
Speed
File System FAT 16/32, exFAT
Maximum Power
Supply Current
DC 5 V
1.5 A
D/A Converter 24 bits
Audio Decoder MP3/WMA/AAC/WAV/FLAC
Video Decoder MPEG1/MPEG2/MPEG4/
WMV/H.264/MKV
Frequency Response 192 kHz Sampling:
20 Hz to 20 000 Hz
96 kHz Sampling:
20 Hz to 20 000 Hz
48 kHz Sampling:
20 Hz to 20 000 Hz
44.1 kHz Sampling:
20 Hz to 20 000 Hz
Total Harmonic
Distortion
0.010% (1 kHz)
Signal to Noise Ratio 98.5 dB
Dynamic Range 89 dB
Bluetooth section
Technology Bluetooth V5.0
Frequency 2.402 GHz to 2.480 GHz
Maximum
Communication
Range
Line of sight approx. 10 m
Audio Codec SBC/AAC
Multi Profile Support Multi Profile
Profile HFP (Hands Free Profile) V1.8
SPP (Serial Port Profile)
A2DP (Advanced Audio
Distribution Profile) V1.3.2
AVRCP (Audio/Video Remote
Control Profile) V1.6.2
PBAP (PhoneBook Access
Profile)
“Dial Error” appears.
→ Dialing has failed. Try the operation again.
“Hung Up Error” appears.
→ The call has not ended yet. Park your car, and use
the connected mobile phone to end the call.
“Pick Up Error” appears.
→ The unit has failed to receive a call.
Bluetooth audio
Bluetooth audio played is disconnected.
→ When iPhone for Apple CarPlay or Android Auto
device is connected, the currently connected
Bluetooth device is disconnected.
The sound is interrupted or skipped while using a
Bluetooth audio player.
→ Reduce the distance between the unit and the
Bluetooth audio player. Disconnect the device
connected for Bluetooth phone if any.
→ Turn off, then turn on the unit.
(When the sound is not yet restored) connect the
player again.
The connected audio player cannot be controlled.
→ Check whether the connected audio player
supports AVRCP (Audio/Video Remote Control
Profile).
TroubleshootingTroubleshooting
63ENGLISH
00DMX7522DABSX.indb6300DMX7522DABSX.indb63 2022/11/1513:312022/11/1513:31
