You have access here to the SNMP configuration. It’s a simple SNMP interface, and you can use an
SNMP browser (like MIB Browser) to manage the SNMP configuration.
The first section allows you to configure the device communities and the port.
Trap sections, is used to enable/disable traps, and set servers on which traps are sent.
Readings sections list all data monitored and their current status. You can also set alarms levels (HIHI,
HI, LO, LOLO).
6.5.3. SNMP manager utilization
A SNMP manager software can communicate with the device by using the SNMP protocol. The user
may have some knowledge about SNMP to use it.
Free SNMP manager software
Some free SNMP managers are available over internet.
A free one is: “iReasoning MIB Browser”. Have a look on the website: “http://www.ireasoning.com/”. You
can download the free one.
Configure the SNMP manager
To configure your SNMP manager to communicate with the device, you need to get the IP address of
the device and set following parameters:
• The read community: “public”
• The write community: “private”
• The SNMP port: “161”
• SNMP version: “v2”
Now your manager should be able to communicate with the device.
