7.1.2. Example of navigation through the front panel
The following sequence occurs after plugging the main supply. Connect the Interlock connector on the
rear panel and make sure the laser pump key is switched OFF (recommended).
For laser with only one diode, only the second diode (Laser Diode 2) is printed on front panel.
Starting
Less than 1 minute is required for boot
sequence.
Please Wait...
Start in progress
-----
v1.6
Presentation
Nominal power and serial number are
displayed.
Presentation screen is removed after about 20
seconds.
KEOPSYS
Fiber Amplifier
27dBm – C Band
SN : 1234567
skip
KEY OFF
Control mode
Shows the configuration.
The highlighted field is moved as the knob is
turned and correspond to the currently selected
field.
Control mode is set to ACC or APC by pushing
the knob where the field ACC or APC is
highlighted.
To change the corresponding set point, turn the
knob to select the value, push the knob on the
actual value and select the new set point by
turning the knob. New set point is saved by
pushing the knob.
The Alarm Status panel as well as the Options
menu can also be selected when highlighted
(see below).
ACC Mode
ACC
Set point D1 : 500mA
Set point D2 : 0mA
Status OK Options
APC Mode
APC
Set point : 20.0dBm
Status OK Options
