Alarm Status
Once the Alarm menu has been selected, the
list of the alarms is shown. It corresponds to the
ALA hexadecimal word (see remote command
set).
Different alarm types are displayed on different
pages. To browse these pages just turn left or
right the knob:
• Diode laser current
• Input and Output Power
• Laser diode and Board Temperatures.
• Benchtop fans
• Others
Just push the knob to back to the previous
window.
Option menu
Options menu pops up the following items:
• Enable or disable the USB Remote Mode
• Enable or disable the RJ45 Remote mode
• Display IP parameters for remote access
through the network (RJ45 Remote)
• Display Benchtop Information
• Access to services window
Highlighted field is selected by pushing the
knob.
USB Remote mode
On choosing the USB remote mode, the front
panel interface enters lock mode. Front panel
access is restored by pushing the knob (USB
remote mode disabled).
In this mode you are able to communicate with
the device using RS232 protocol with rear panel
USB connector.
RJ45 Remote mode
On choosing the RJ45 remote mode, the front
panel interface enters lock mode. Front panel
access is restored by pushing the knob (RJ45
remote mode disabled).
In this mode you are able to communication
with the device using Telnet protocol with rear
panel RJ45 connector.
Available only if Telnet option is available.
