IP Settings
IP configuration can be set by selecting the
Configure field.
IP address, Mask, and Gateway are
automatically assigned when DHCP field is ON.
Fixed configuration can also be chosen (static
IP) by setting DHCP to OFF position.
Push knob on the validate field to save the
configuration.
Link up or Link down indicates if the device is
connected to the network.
IP :192.168.193. 20
Mask :255.255.240. 0
Gw :192.168.192.254
DHCP : On
Link up
Configure Back
Device Information
The Information field provides data related to
the device for identification purposes:
• Laser production family (ex. 33dBm C-
Band)
• Software Version
• Hardware Version
• Serial Number
• Manufacturing Date
27dBm – C Band
Version : BT1Uv00487
HW Version : 2.0
SN : 1234567
Manufacturing Date :
2016-06-12
Back
Services
This page is used to update software of the
device using USB key. In this case, you may
use only firmware provided by Keopsys.
You can also save device logs on an USB key
Before use any of these entries, an USB key
need to be connected.
Upgrade BT Fw
This entry allows you to upgrade the benchtop
interface firmware.
Selecting it, a new page asks you to select the
correct firmware file among all *.tgz files found
on the root of your USB key.
Select a file will immediately start benchtop
firmware upgrade process.
Upgrade BT Fw
Upgrade Module Fw
Save log file
Save MIB file
Back
Select a file
kps1U-00718.tgz
Back
