User’s Manual
Published on February 2017 UMn°154 – rev.05 35
This document and any information disclosed herein are the property of Keopsys and constitutes and contains proprietary information.
Receipt or possession of this document does not confer or transfer any right to duplicate, use disclose any information
Upgrade Module Fw
This entry allows you to upgrade the firmware
of an optical module.
Selecting it, a new page asks you to select the
correct firmware file among all *.bin files found
on the root of your USB key.
After selecting a file, a new page asks you to
select the module on which you want to perform
the upgrade. Commonly only one module is
used and it’s the slot 1.
Select a slot will immediately start module
firmware upgrade process.
Save log file
Selecting this entry will immediately save on
your USB key all log files (up to 7).
Save MIB file
This entry is available only if SNMP option is
available. Selecting it will immediately save the
MIB file for SNMP on your USB key.
Select a file
K2SEv4.03.bin
Back
Select a slot
Slot 1
Slot 2
Slot 3
Back
Settings
You can access here to additional user
configurations.
Brightness
Set the screen brightness from 0 (dark) to 255
(bright).
KEY ON and pump button ON
Ensure you have completely read the general safety considerations.
Key ON position doesn’t start laser emission but allows it. Beware,
laser emission can now be started remotely (WSI, RS232, Telnet,
SSH).
Key ON position and Start Button pressed on, lead to switch on the
laser pump.
When an optical signal is applied in the input fiber, even if one of the
diode is shut down, invisible laser radiations are present in the output
fiber.
AVOID DIRECT EXPOSURE TO THE BEAM
