KERN CDS 4K0.02 User Manual

9 TCDS-BA-e-2210
3.2 Operating elements
3.2.1 Keyboard overview
Button
Name
Function in Operating mode
Function in Menu
ON/OFF-
button
➢ Switch on/off
(press button long time)
➢ Switch on/off the display
background illumination
(press button long time)
➢ Menu level back
➢ Exit menu / back to
weighing mode.
TARE-button
➢ Taring
➢ Zeroing
➢ PRE-TARE
(press button long time)
➢ Invoke application
menu (press button
long time)
➢ Activate menu item
➢ Confirm selection
5 x
➢ Reference quantity "5“
10 x
➢ Reference quantity "10“
REF n
➢ Freely selectable
reference quantity
(long key pressing;
see chap. 9.2)
20 x
➢ Reference quantity "20“
Shift key
➢ Switch over between
weight display and piece
quantity display
➢ Navigation key 
PRINT button
➢ Calculate weighing data
via interface
➢ Navigation key 
