KERN CDS 4K0.02 User Manual

TCDS-BA-e-2210 4
1 Technical data
KERN
CDS 4K0.02
CDS 15K0.05
CDS 16K0.1
Item no./ Type
TCDS 4K0.02-A
TCDS 5K0.05-A
TCDS 16K0.1-A
Readability (d)
0.02 g
0.05 g
0.05 g
Weighing range (max)
4 kg
15 kg
16 kg
Reproducibility
0.04 g
0.1 g
0.1 g
Linearity
±0.1 g
±0.25 g
± 0.3 g
Smallest part weight for
piece
counting - under lab
conditions*
20 mg
50 mg
100 mg
Smallest part weight for
piece
counting - under normal
conditions**
200 mg
500 mg
1 g
Adjustment points
1/2/4 kg
5/10/15 kg
5/10/15 kg
Recommended
adjustment weight (not
supplied)
4 kg (F1)
15 kg (F1)
15 kg (F1)
Stabilization time (typical)
3 sec.
Warm-up time
120 min
Weighing Units
kg, g, gn, dwt, ozt, ct, lb, oz, FFA
Humidity of air
max. 80% rel. (non-condensing)
Allowable ambient
temperature
10 °C ... + 40 °C
Input voltage Appliance
6V, 1A
Input voltage Mains
adapter
100 V - 240 V AC, 50/60 Hz
Rechargeable battery
operation (optional)
Operating period 48 h (background illumination OFF)
Operating period 24 h (background illumination ON)
Loading time approx. 8 hrs.
Auto-Off (battery,
rechargeable battery)
selectable off, 30s, 1, 2, 5, 30, 60 min
Dimensions housing
(W x D x H) [mm]
225 x 115 x 60
Weighing pan
228 x 228 x 95mm
Metal, lacquered
308 x 318 x 75 mm
Metal, lacquered
Net weight (kg)
4.1
7.5
Interfaces
RS-232 (optional), USB device (optional) via KUP
Underfloor weighing
device
no
yes (hook optional)
